Specifications

Display
Analog camera
Analog camera > Inputs
16CH(1Vp-p 75ohm, BNC)
Analog camera > Signal Type
– AHD(8MP, 5MP, 4MP, 1080p, 720p) – HDTVI(8MP, 5MP, 4MP, 1080p, 720p) – HDCVI(8MP, 5MP, 4MP, 1080p, 720p) – NTSC/PAL
Network camera
Network camera > Inputs
2CH (Up to 18CH)
Network camera > Resolution
8MP ~ CIF
Network camera > Protocols
SUNAPI(Wisenet), ONVIF
Live
Live > Local Display
1x HDMI, 1x VGA (Dual monitor) HDMI: 3840 x 2160, 2560×1440, 1920×1080, 1280×1024, 1280×720 VGA: 1920×1080, 1280×1024, 1280×720, 1024×768
Live > Resolution
[Analog Camera(NTSC/PAL)] – 8MP(15/12fps), 5MP(20/12fps), 4MP(30/25fps), 2MP(30/25fps),1MP(30/25fps), 960H(or 720H)(30/25fps) * per CH [Network Camera] – Typ. 2MP(480fps)
Performance
Record
Record > Compression
H.265, H.264, MJPEG
Record > Record Rate(Analog)
(Main Stream, NT/PAL) 8M 8/8fps, 5M 12/12fps, 4M 15/12fps, 2M 30/25fps, 720p 30/25fps, Under 960H 30/25fps/CH (Sub Stream) 720p/CH or Higher : 640×368 Full fps, SD : upto SD Full fps * The maximum recording frame rate depends on the frame rate of the input camera.
Record > Recording Bandwidth
Max. 128Mbps (HRX-1635)
Record > Resolution
8MP ~ CIF
Record > Mode
Normal, Dual Stream, Schedule(Continuous/Event), Event (Pre/Post), Bookmark
Record > Event Trigger
Alarm Input, Video Loss Analog Camera : Video Loss, Motion Detection, Tampering Network Camera : Camera Event(Sensor, MD, Video Analytics, Defocus, Audio), Dynamic Event, User Event
Record > Event Action
e-Mail, Event Push, PTZ Preset, Alarm Out, Buzzer, Monitor Out, FTP, SUNAPI Command, Shotdown
Search & Play
Search & Play > Playback Bandwidth
Max. 32Mbps (18CH simultaneously)
Search & Play > User
Max. 4 users (Set 1, Remote 3)
Search & Play > Simultaneous playback
18CH(Local Monitor),18Ch (CMS), 4Ch (Wisenet Mobile), 1Ch(Web)
Search & Play > Fisheye Dewarping
CMS (only N/W Camera)
Storage
Storage > Supported HDD
Up to 6TB
Storage > HDD Slot
SATA 8ea(Max. 48TB)
Backup
Backup > File backup
Set : Recorder, SEC, AVI Webviewer : AVI
Backup > Function
Max. 16 CH play, Date-time/title display
Functions
PTZ
PTZ > Control
Via GUI, Webviewer, SSM, SmartViewer, Wisenet Mobile Viewer, System Controller
Smart phone
Smart phone > Support Model
iOS, Android
Smart phone > Protocol Support
RTP, RTSP, HTTP, CGI(SUNAPI)
Smart phone > Control
Live(16ch) : Multi-Profile Support Playback(4Ch Multi Playback, Max 2MP) Event push
Smart phone > Max. Remote Users
Search(3), Live Unicast(10)
Redundancy
Redundancy > ARB
Support
Easy configuration
Setup Wizard (Language Date/Time, Password, Network, Auto Camera Configuration), P2P (QR code)
Coaxial Control
CVBS(Pelco-C)/AHD/CVI/TVI
Interface
HDMI
1EA
VGA
1EA
BNC
16CH In / 1CH Out(Spot Output)
Audio
Out(1EA, RCA, Line)
Ethernet
RJ-45(10/100/1000BASE-T)
Alarm
In 16EA, Out 4EA – Relay Out1(NO/NC/COM) – Relay Out2~4(NO/COM)
USB
2EA(Front USB2.0, Rear USB 3.0))
Serial(Protocols)
RS-485/422 (Samsung-T/Pelco-D/Pelco-p) * for PTZ
Power inlet
1EA AC ( AC100V)
System
System Control
Mouse, Webviewer, System Controller(SPC-7000, SPC-6000, SPC-2000)
Language
English, French, German, Italian, Spanish, Russian, Turkish, Polish, Dutch, Swedish, Czech, Portuguese, Danish, Rumanian, Serbian, Croatian, Hungarian, Greek, Norwegian, Finnish, Korean, Chinese, Japanese, Thai
Environmental
Operating Temperature
0°C to +40°C(+32℉ to +104℉)
Operating Humidity
20% ~ 85% RH
Certification
UL, CE, FCC, KC, UKCA
Electrical
Power Input
100~240 VAC±10%, 50/60 Hz
Power Consumption
Max. 200W (6T HDD 8ea)
Mechanical
Color / Material
Black / Metal
Dimension (WxHxD)
440 x 88 x 384.8mm(17.32” x 3.46” x 15.15”)
Weight
Approx. 7.70Kg (17 lb, 4TB HDD 1ea)
Network
Protocol
TCP/IP, UDP/IP, RTP (UDP), RTP (TCP), RTSP, NTP, HTTP, DHCP (Server, Client), PPPoE, SMTP, ICMP, IGMP, ARP, DNS, DDNS, uPnP, HTTPS, SNMP, ONVIF (Profile-S), SUNAPI(Server, Client)
DDNS
Wisenet DDNS
Transmission speed
– Analog Camera(NTSC/PAL) (Main Stream) 8MP 8/8fps CH, 5M 12/12fps CH, 4M 15/12fps CH, 2M 30/25fps CH, 720p 30/25fps/CH, SD 30/25fps/CH (Sub Stream) 720p or higher : 640×368 full fps/CH, SD signal : upto CIF full fps/CH * The maximum recording frame rate depends on the frame rate of the input camera.
Transmission Bandwidth
Max. 100Mbps
Audio
Audio > Input/Output
16 Lline in (RCA 4 Line, Option : Audio Extension Cable) / 1Line line out
Audio > Compression
G.711 (N/W Camera G.711, 726)
Audio > Audio Communication
2-Way
Max Remote Users
Search(3), Live Unicast(10), Multicast(20)
Security
IP address filtering, User access log, 802.1x Authentication, Encryption (ID/PW, Recording, Transmission, Backup) Device Certificate(Hanwha Techwin Root CA)
Viewer Software
SSM, Webviewer, SmartViewer, Wisenet Mobile Viewer, Wisenet Viewer Support SDK/CGI(SUNAPI) for integration to 3'rd party VMS
